Reconstruction of the I-30S & Hwy 5 intersection.

This intersection has remained unchanged for quite some time, and functioned perfectly well when the region was less built up, and Rockwall was less built up. A couple new exits were haphazardly constructed in order to hopefully ease the growing traffic. However, this achieved the oppesite effect as new medium density and high density buildings began to sprout up around these new exits, in turn causing worse traffic problems. Unfortunately, the current infastructure built for the intersection causes huge traffic backups, I mean lots of red congestion.

In fact, as you can observe, the congestions backs all the way to one of the main shopping centers in town, located south of the intersection.

Let us now undergo the reconstruction process, and in doing so relieving some of the traffic problems. We will rebuild this intersection with the least amount of demolition possible. For if this was real life, most of the land and buildings here would be too expensive for any state to buy and use for roadways.

Phase I

As Phase I is completed, we have diverted the majority of the problem. Northbound Hwy 5 now has a way to get onto I-30S without stopping. This will relieve most traffic. However our work is not yet finished, because that only solves their morning commute troubles. In Phase II, we will address the evening issues.

Phase II

Now we have added a way for evening commuters coming from Bowden via eastbound I-30S to connect to Hwy 5 southbound more easily. In doing so, we will also free up traffic heading northbound on Hwy 5 as well. Next, the finishing touches.

Phase III

We have finished our new intersection. We have left some of the old in place, while adding new overpasses and onramps. This will allow traffic to more easily flow through and around this major intersection.

Here is a new look at the traffic:
